The Structure Of The Connection Cable

Comprise three single-core connecting wires, adhesive layer; three single-core connecting wires are placed in a zigzag shape, and the sheath layer of adjacent single-core connecting wires is outward-tangent, and in any cross-section, the connecting wire of the center of the transmission conductor of three single-core connecting wires is in a straight line; it is characterized in that two slow-speed charging wires, a grounding wire, a control wire are arranged in the four outer clearances of adjacent single-core connecting wires, and slow-speed charging wires, grounding wires, The control wires are located within the bond layer, the upper and lower surfaces of the bond layer are single planes, and the outer diameters of the three single-core connecting wires are equal.

Softer, easier to bend, better heat resistance and insulation, better shielding and heat dissipation performance, easier to make, lower cost, more convenient and reliable connection, safer products.
